Insulated Wine Fermenters for Grape Fermentation

Our Insulated Wine Fermenters are specially engineered for optimal grape fermentation processes, combining advanced insulation technology with durable construction to meet the diverse needs of winemakers worldwide. Available in a wide range of working volumes from 500L to 50,000L, these fermenters are designed to maintain precise temperature control throughout the fermentation cycle, a critical factor in preserving grape aromas and enhancing wine quality.

Each unit features a robust structure with customizable dimensions, including varying diameters and heights (e.g., 800800mm for 500L models up to 35005200mm for 50,000L units) to fit different production scales. The PU insulation layer, ranging from 50mm to 80mm depending on the capacity, ensures minimal heat loss, while the stainless steel construction (inferred from industry standards) guarantees longevity and resistance to corrosion. A key advantage is our commitment to customization—all parameters, from inlet/outlet diameters to manway sizes, can be tailored to specific process requirements, making these fermenters suitable for both small-batch artisanal wineries and large-scale industrial operations.

Product Features

Superior Thermal Insulation

The core of our fermenters lies in their high-performance insulation system. Models with 500L to 10,000L working volumes are equipped with a 50mm PU insulation layer, while larger units (20,000L to 50,000L) feature an enhanced 80mm PU insulation layer. This polyurethane foam material boasts low thermal conductivity, effectively stabilizing internal temperatures to prevent fluctuations that could compromise fermentation. Such insulation performance aligns with industry standards for cold storage applications, ensuring consistent conditions even in varying ambient environments.

Durable Construction & Accessibility

• Inner Thickness: Ranging from 3mm (for 500L to 20,000L models) to 4mm (for 40,000L and 50,000L units), the thickened stainless steel inner wall enhances durability and resistance to pressure during fermentation.

• Inlet/Outlet Design: Equipped with 38mm diameter ports for smaller capacities (500L to 2000L) and 76mm ports for larger units (40,000L to 50,000L), facilitating efficient grape must transfer and reducing processing time.

• Manway Sizes: Designed for easy access during cleaning and maintenance, with sizes such as 440*320mm (500L to 1000L) and 550*430mm (2000L to 50,000L) ensuring convenient operation.

Customizable Engineering

All fermenters are fully customizable to meet unique operational needs. Whether adjusting dimensions, modifying insulation thickness, or altering port sizes, our flexible manufacturing process ensures that each unit aligns with specific winemaking protocols. This adaptability makes our fermenters a versatile choice for wineries seeking tailored solutions.

Technical Specification

Applications

Medium-Scale Production Facilities

Wineries with moderate output (3000L to 10,000L) benefit from the fermenters’ efficient heat retention and durable build. The 50mm PU insulation maintains stable conditions during extended fermentation cycles, while the 51mm ports support higher throughput without sacrificing quality.

Large-Scale Industrial Operations

For mass production needs, our 20,000L to 50,000L fermenters deliver unmatched performance. The 80mm insulation layer and 76mm ports handle high-volume processing, ensuring consistent results across large batches. Their robust 4mm inner thickness withstands heavy usage, making them suitable for year-round production schedules.

FAQ

What working volumes are available for these insulated wine fermenters?

Our fermenters cover a comprehensive range, from 500L up to 50,000L, ensuring options for every production scale, from small artisanal wineries to large industrial facilities.

Can the fermenters be customized to fit specific production needs?

Yes, all parameters—including dimensions, insulation thickness, inlet/outlet diameters, and manway sizes—are fully customizable according to your process requirements. This flexibility allows seamless integration into existing production lines.

What insulation material is used, and how does it enhance fermentation?

We use high-quality PU (polyurethane) foam with thicknesses of 50mm or 80mm. This material minimizes heat transfer, maintaining stable internal temperatures critical for yeast activity and flavor development, which is essential for premium wine production.

How do the inlet/outlet diameters vary across different models?

Smaller fermenters (500L to 2000L) feature 38mm diameter ports, while medium models (3000L to 20,000L) use 51mm ports. Larger units (40,000L to 50,000L) are equipped with 76mm ports to accommodate higher flow rates during transfer processes.

What maintenance practices are recommended for these fermenters?

Regular cleaning with soft brushes (avoiding abrasive tools) is advised to preserve the inner surface. The manway sizes (e.g., 440320mm, 550430mm) allow easy access for inspection, and we recommend annual calibration of temperature sensors to ensure accuracy.
